Test or certification item 测试或认证名称: 集装箱涂料 美国KTA认证

Refer products 涉及产品:  集装箱涂料

Test info 测试要求:

Standard Method Parameters
IICL Specification Steel Panels1
IICL Specification Abrasive Blast Cleaning
Conventional Spray Application Coating Application
ASTM D2244-16 Color (pre, post and ΔE* calculation)
ASTM D523-14(18) Gloss (pre, post and Δ gloss)
ASTM D7091-13 Dry Film Thickness
ASTM D1654-08(16)e1 Scribing
IICL Specification QUV Exposure
IICL Specification, ASTM G85-11, Modified Cyclic Salt Fog Exposure
IICL Section 3.8.2 Humidity Cycling
Not Applicable Cyclic Handling Fee
ASTM D714-02(17) Degree of Blistering
ASTM D610-08(12) Degree of Rusting
ASTM D1654-08(16)e1 Undercutting
ASTM D3359-17 Tape Adhesion
ASTM D2794-93(10) Impact – Direct and Reverse
ASTM D4060-14 Taber Abrasion
Project Coordination and Report Preparation


Lead time 周期:  常规服务 regular service 18-20 周 weeks 工作日 working days ( URGENT service, to be confirm, 加急服务待定 )

Sample size 送样规格:

Please provide one US liquid quart of each coating material (minimum)

If the zinc primer and second coat are the same for more than one system, please provide additional US liquid quarts of the zinc primer and second coat for each coating system.


片材样品提供方案 Institute of International Container Lessors (IICL)

Panel Specimen Preparation:

Prepare (12) test panels measuring 3" x 6" x 1/16" for each exterior system.

Prepare (12) test panels measuring 3" x 6" x 1/16" plus (2) 4" x 4" x 0.032" Taber abrasion panels for each interior system.

Use steel conforming to Japanese Industrial Standard G3101 (type SS41) or its equivalent (such as ASTM A36, etc.). The steel shall be abrasive blasted to Swedish standard SA 21/2with a surface profile between 25-40 microns.

Comments:

Coat both panel sides and protect edges on all 3"x 6" panels. Coat one side of Taber panels with 1/4" hole drilled in the center

4" x 6" panels could also be used in place of 3" x 6" panels.

Send dry film thickness (DFT) measurements of each coating layer. These measurements can either be listed on the back of the panels using a label or sent in a spreadsheet.


Others 其他信息:

Digital photographs are not included but can be provided if required for additional costs.

If A36 grade steel cannot be acquired in 1/16′′ thickness, the 1⁄8′′ thick steel will be used for every test except impact testing, which will be prepared using commercial grade steel at 1/16′′thickness.

Testing will be entered into the queue upon receipt of the samples and a signed authorization to proceed.

Payment in full via wire transfer is required prior to initiation of testing. Upon receipt of the signed ATP, information for the wire transfer will be provided.

If baking is required for curing, an additional cost of $150.00 per coating layer will be incurred.
