Test or certification item 测试或认证名称: ISO 4180 包装 - 完整的填充运输包装
编制性能测试计划的一般规则 - 用于重量小于 30 公斤的包装 - 2 级
Packaging - Complete, filled transport packages - General rules for the compilation of performance test schedules - for packages of mass less than 30 kg- Level 2
编制性能测试计划的一般规则 - 用于重量小于 30 公斤的包装 - 2 级
Packaging - Complete, filled transport packages - General rules for the compilation of performance test schedules - for packages of mass less than 30 kg- Level 2
Test or certification info 测试和认证相关内容:
|
Conditioning -72hours (Client can specified the conditions) 环境仓-72小时（客户可指定条件） |
|
Shock- Drop Tests 冲击跌落测试 |
|
Compression- Static Load 压缩-静态负载 |
|
Transport Vibration -Vibration 运输振动-振动 |
|
Transport Vibration -Repetitive shock 运输振动-重复冲击 |
|
Compression- Static Load 压缩-静态负载 |
|
Shock- Drop Tests 冲击跌落测试 |
| Basic factor in logistics | Hazard | Related international standards | |
| Transport | — Vibration during transportation — Repetitive impact by bouncing |
Vertical random vibration test | ISO 13355 |
| Sinusoidal vibration tests using a variable frequency | ISO 8318 | ||
| Vibration tests at fixed low frequency | ISO 2247 | ||
| Horizontal impact by sudden stop or start | Horizontal impact test | ISO 2244 | |
| Horizontal impact by linking work of rail- way freight car | |||
| Stacking stress during transportation | Random vibration test | ISO 13355 | |
| Sinusoidal vibration tests using a variable frequency | ISO 8318 | ||
| Low pressure by high altitude | Low pressure test | ISO 2873 | |
| Handling | Drop impact by manual handling | Vertical impact test by dropping | ISO 2248 |
| Drop impact by mechanical handling | EN 14149 | ||
| Horizontal impact during handling by forklift or crane as such | Horizontal impact test | ISO 2244 | |
| Rough handling by rolling | Rolling test | ISO 2876 | |
| Topple | Toppling test | ISO 8768 | |
| Handling of unit load | Stability testing of unit loads | ISO 10531 | |
| Storage | Compression load in stacking storage in warehouse | Stacking tests using a static load | ISO 2234 |
| Compression and stacking tests using a compression tester | ISO 12048 | ||
| Climate | Temperature and humidity | High temperature test | ISO 2233 IEC 60068-1 |
| High temperature/High humidity test |
|||
| Low temperature test | |||
| Wet, dewing | Water-spray test | ISO 2875 | |
Refer products 涉及产品: 货物外包装
Lead time 周期: 常规服务 regular service 7-9 工作日 working days （ URGENT service, to be confirm, 加急服务待定 ）
Sample size 送样规格: 1 Carton 箱但是外面要再套个包装箱
Others 其他信息:
Photo for reference 涉及图片:
Photo for reference 涉及图片:
Sample report 样本报告：
