EN 16927返回 Back


Test item
测试名称:EN 16927 Mini-pools — Specific requirements including safety and test methods for minipools

小型游泳池.包括小型游泳池的安全性和试验方法的特殊要求


Test info 测试内容:

Clause

Test Requirement

4

General requirements and test methods

4.1

General

4.2

Mini-pools with frame-supported walls and rigid walls

4.2.1

Resistance to horizontal deformation

4.2.2

Resistance to vertical deformation

4.2.3

Bursting strength

4.3

Mini-pools with self-stabilizing or inflatable walls

4.3.1

Capacity to stop an overflow

4.3.2

Inflatable compartments

4.3.3

Stability in the event of deflation of the upper tube of mini-pool with self-stabilizing walls

4.3.4

Bursting strength

4.4

Tolerances

4.5

Minimum performance requirements for structural materials

4.5.1

General

4.5.2

Specific requirements and testing for corrosion resistance

4.5.2.1

Metal products96hrs NSS

*4.5.2.2

Wood,需提供相应木材符合性报告,具体见Remark 1

4.6

Injury risks

4.6.1

Small elements, edges and corners

4.6.2

Permissible openings

*4.7

Accessibility

5

Instructions for the consumer

适用范围

mini-pool

non permanently installed artificial aboveground basin:

— with a maximum wall height<850mm;

— with a water depth, measured between the overflow level and  the deepest point within the pool of >400mm;

— with a maximum effective water volume of <6m3

— and where the means of filtration and water treatment are not required

Remark 1:

备注1:

Structural elements made of wood or wood-based material shall meet the following requirements according to EN 335:
— use class 3 if they are not in direct contact with ground and / or fresh water;
— use class 4 if they are in direct contact with ground and / or fresh water.
Compatible woods may be chosen according to two distinct approaches:
— using naturally durable woods (excluding sapwood) as defined in EN 350-2, that meet the requirements for use in applicable hazard classes in EN 460;
— using wood with conferred durability (preservation treatments while conserving the sapwood), that meets the requirements for use in applicable hazard classes in EN 351-1.

Remark 2:
备注2:

The quotation of 4.7 Accessibility doesn't include the specific means of access,  If a specific means of access is used (e.g. ladder) such means of access shall comply with requirements for safe means of access specified in EN 16582-1:2015, 5.4.4.


Lead time 测试周期:  常规 regular service 12 working days


Sample size 送样规格3 套完整样品带说明书和适用的安装配件


Responsive image

Responsive image

Responsive image


Sample for reference 参考图片:

Responsive image



Sample Report:

Responsive image
