EN 15194返回 Back
Test item 测试名称: EU test requirement for e-bike 欧盟电动自行车标准
Test info 测试内容：
Complete sample requirement 完整样品要求:
5 sets of fully assembled bicycle, 4 pcs of brake pad (if applicable), 3 pcs of fork, 3 sets of frame & fork assembly, 4 pcs of chain, 3 set of handlebar & stem assembly, 2 set of saddle and seat pillar assembly, 1 set of crank assembly, 2 pcs of pedal, 4 pcs of bell (if applicable), 3 pcs of luggage carrier with nuts (if applicable), 2 additional pcs of fork for disc brake/hub brake, 1 pc of instruction, 2 sets of motor, 1 set of battery, 1 set of charges, 2 sets of other electric parts
整车5套,闸皮4块(若适用),前叉3支,车架前叉组件3套,链条4根,把横管/把立管组件3套,鞍座及鞍管组合件2套，曲柄组件1套,脚蹬2个，车铃4件(若适用),衣架3件(若适用),额外2支前叉(轮毂闸或盘闸)，说明书1套, 额外电机2套，额外电池1套，额外充电器1套，额外其他电气原件2套。
Turnaround time: normal(30 working days)
工作天: 普通件(30个工作天)
Informaiton required for apply testing 测试必须信息
1. 整车测试：各紧固件的锁紧扭力
零部件测试：
车闸：自行车类型，各紧固件的锁紧扭力
车把：自行车类型，车把横管和立管的锁紧扭力
车架：自行车类型，车架头管下端到轮轴距离，车轮尺寸
前叉：自行车类型，前叉使用在多大的车轮直径上（24”, 26”, 650B, 29”or700c，针对条款
车轮转动精度：自行车类型，车闸类型（Intended for rim-brakes， Not intended for rim-brakes）
脚踏：自行车类型
鞍座鞍管：自行车类型，鞍座锁紧扭力 产品标签，说明书
2. 关于反射器的测试ISO 6742‑2，客服同事须在进单前确认以下操作，三种情况其中一种，并在申请表中注明
a.申请测试；
b.提供报告：报告须有结论，报告型号与实际反射器型号一致，有效期1年；
c.此项目NT
|
EN 15194 电动自行车 This European Standard applies to EPAC for private and commercial use with exception of EPAC intended for hire from unattended station. This European Standard is intended to cover all common significant hazards, hazardous situations and events (see Clause 4) of electrically power assisted bicycles, when used as intended and under condition of misuse that are reasonably foreseeable by the manufacturer. This European Standard is intended to cover electrically power assisted bicycles of a type which have a maximum continuous rated power of 0,25 kW, of which the output is progressively reduced and finally cut off as the EPAC reaches a speed of 25 km/h, or sooner, if the cyclist stops pedalling. This European Standard specifies requirements and test methods for engine power management systems, electrical circuits including the charging system for the assessment of the design and assembly of electrically power assisted bicycles and sub-assemblies for systems having a rated voltage up to and including 48 V d.c. or integrated battery charger with a 230 V a.c. input. This European Standard specifies safety and performance requirements for the design, assembly, and testing of EPAC bicycles and subassemblies intended for use on public roads, and lays down guidelines for instructions on the use and care of such bicycles. This European Standard applies to EPAC bicycles that have a maximum saddle height of 635 mm or more and that are intended for use on public roads. |
| Safety requirements and/or protective measures 安全要求与/或保护措施 |
| General (ISO 12100) 一般要求 |
| Electrical requirements 电气要求 |
| Electric circuit 电路 |
| Controls and symbols 控制与标志 |
| Batteries 电池 |
| Battery charger 电池充电器 |
| integrated battery charger (LVD) |
| external battery charger (LVD CERTIFICATE REVIEW) |
| Electric cables and connections 电线和联结 |
| Wiring 布线 |
| Power cables and conduits 电源线和导电管 |
| External and internal electrical connections 内部和外部连接 |
| Moisture resistance 防潮测试 |
| Mechanical strength test 机械强度 |
| Maximum speed for which the electric motor gives assistance 辅助动力最大速度 |
| Start-up assistance mode 起动辅助模式 |
| Power management 功率管理 |
| Maximum power measurement |
| Electro magnetic compatibility 电磁兼容 |
| Emission 电磁干扰 |
| Immunity 抗干扰能力 |
| Battery charger 电池充电器 |
| Failure mode 失效模式 |
| Anti-tampering measure 防篡改措施 |
| Mechanical requirements |
| Sharp edges 锐边 |
| Security and strength of safety-related fasteners 与安全有关的紧固件的可靠性 |
| Protrusions 突出物 |
| Brakes 车闸 |
| Braking-systems 制动系统 |
| Hand-operated brakes 手闸 |
| Attachment of brake assembly and cable requirements 车闸部件的安装和 |
| Brake-levers Position of applied force 闸把施力部位 |
| Brake-block and brake-pad assemblies-security test 闸皮和闸盒组合件-强度测试 |
| Brake adjustment 车闸的调整 |
| Hand-operated braking system- strength test 手闸制动系统-强度测试 |
| Back-pedal braking system- strength test 脚闸制动系统-强度测试 |
| Braking performance 制动性能 |
| Brakes-heat-resistance test 车闸-耐热测试 |
| Back-pedal brake linearity test 脚闸线性测试 |
| Steering 车把 |
| Handlebar - Dimensions 把横管-尺寸 |
| Handlebar grips and plugs 把横管的把套和把盖 |
| Handlebar stem -insertion-depth mark or positive stop 把立管-插入深度标记或有效档块 |
| Handlebar stem to fork steerer-clamping requirements 把立管对前叉立管-夹紧要求 |
| Steering stability 车把稳定性 |
| Steering assembly-Static strength and security tests车把部件-静负荷强度和可靠性测试 |
| Handlebar stem/Handlebar and stem assembly-lateral bending tests 把立管 |
| Handlebar-stem-forward bending test 把立管-向前弯曲测试 |
| Handlebar to handlebar-stem-torsional security test 把横管对把立管-扭矩安全测试 |
| Handlebar-stem to fork-stem-torsional security test |
| Bar-end to handlebar-torsional security test 把端把对把横管-扭矩安全测试 |
| Handlebar and stem assembly - Fatigue test 把横管和把立管组合件 - 疲劳测试 |
| Frame 车架 |
| Suspension frame - Special requirements 避震车架-特殊要求 |
| Frame — Impact test (falling mass) 车架-冲击测试(落重) |
| Frame and front fork assembly — Impact test (falling frame) |
| Frame-Fatigue test with pedalling forces 车架-脚蹬力疲劳测试 |
| Frame-Fatigue test with a Horizontal force 车架水平力疲劳测试 |
| Frame-Fatigue test with a vertical force 车架垂直力疲劳测试 |
| Front fork 前叉 |
| Means of location of the axle and wheel retention 前轴和前轮的夹紧定位方式 |
| Suspension fork - Special requirements 避震前叉-特殊要求 |
| Tyre clearance test 轮胎间隙 |
| Tensile test 拉伸测试 |
| Front fork - Static bending test 前叉-静弯曲测试 |
| Front fork - Rearward impact test 前叉-向后冲击测试 |
| Forks made entirely of metal 全金属前叉 |
| Forks which have composite parts 带合成材料前叉 |
| Front fork - Bending fatigue test plus rearward impact test |
| Forks intended for use with hub - or disc brakes 用于轮毂闸或盘闸的专用前叉 |
| Tensile test for a non-welded fork 非焊接前叉拉伸强度 |
| Wheels and Wheel/tyre assembly 车轮和车轮/轮胎组合件 |
| Wheel/tyre assembly-concentricity and lateral tolerance 车轮/轮胎组合件-径向轴向圆跳动公差 |
| Wheel/tyre assembly - Clearance 车轮/轮胎组合件-间隙 |
| Wheels - Static strength test 车轮-静负荷测试 |
| Wheels - Wheel retention 车轮-车轮的夹持 |
| Wheels - Quick release mechanisms 车轮-快卸机构 |
| Rims , Tyres and tubes 轮辋、外胎和内胎 |
| Tyre inflation pressure 轮胎充气气压 |
| Tyre and rim compatibility (ISO 5775-1/2) 轮胎和轮毂匹配度 |
| Rim-wear 轮毂磨损 |
| Greenhouse effect test for composite wheels 复合材料温室效应 |
| Front Mudguards 前挡泥板 |
| Pedals and pedal/crank drive system 脚蹬和脚蹬/曲柄驱动系统 |
| Pedal tread 脚蹬脚踩面 |
| Pedal clearance 脚蹬间隙 |
| Pedal/pedal spindle assembly - Static strength test 脚蹬和脚蹬轴组合件-静符合测试 |
| Pedal spindle - Impact test 脚蹬轴-冲击测试 |
| Pedal- Dynamic durability test 脚蹬-动态耐久性测试 |
| Drive system - Static strenght test 驱动系统-静负荷测试 |
| Crank assembly - Fatigue test 曲柄组合件疲劳测试 |
| Drive-chain and drive belt 传动链与传动带 |
| Drive-chain 传动链 |
| Drive belt 传动皮带 |
| Chain-wheel and belt-drive protective device 链轮与皮带轮保护装置 |
| Chain-wheel disc and drive pulley disc diameter 链轮盘与驱动盘直径 |
| Chain and drive belt protective device 链轮盘保护装置 |
| Combined front gear-change guide 整合式前轮拨 |
| Saddles and seat-pillars 鞍座和鞍管 |
| Limiting dimensions 限制尺寸 |
| Seat-post — Insertion-depth mark or positive stop 鞍管-插入深度标记或有效档块 |
| Saddle/seat-post — Security test 鞍座/鞍管-安全性测试 |
| Saddle — Static strength test 鞍座-静负荷测试 |
| Saddle and seat-pillar clamp-Fatigue test 鞍座和鞍座夹紧装置 - 疲劳测试 |
| Saddle and seat-post clamp — Fatigue test 鞍管疲劳测试 |
| Spoke connector 辐条保护盘 |
| Luggage carriers 衣架 |
| Road test of a fully assembled bicycle 完整自行车路况测试 |
| Lighting systems and reflectors |
| Wiring harness |
| Lighting systems （ISO 6742‑1） |
| Reflectors （ISO 6742‑2） |
| Warning device 鸣号装置 |
| Thermal hazards 热危害 |
| Performance Levels (PLr) for control system of EPACs （ISO 13849） |
| List of significant hazards and performance levels 重大危害列表与性能水平 |
| Significant hazards 重大危害 |
| Marking and labelling 标签 |
| Instructions for use 使用说明书 |
Complete sample requirement 完整样品要求:
5 sets of fully assembled bicycle, 4 pcs of brake pad (if applicable), 3 pcs of fork, 3 sets of frame & fork assembly, 4 pcs of chain, 3 set of handlebar & stem assembly, 2 set of saddle and seat pillar assembly, 1 set of crank assembly, 2 pcs of pedal, 4 pcs of bell (if applicable), 3 pcs of luggage carrier with nuts (if applicable), 2 additional pcs of fork for disc brake/hub brake, 1 pc of instruction, 2 sets of motor, 1 set of battery, 1 set of charges, 2 sets of other electric parts
整车5套,闸皮4块(若适用),前叉3支,车架前叉组件3套,链条4根,把横管/把立管组件3套,鞍座及鞍管组合件2套，曲柄组件1套,脚蹬2个，车铃4件(若适用),衣架3件(若适用),额外2支前叉(轮毂闸或盘闸)，说明书1套, 额外电机2套，额外电池1套，额外充电器1套，额外其他电气原件2套。
Turnaround time: normal(30 working days)
工作天: 普通件(30个工作天)
Informaiton required for apply testing 测试必须信息
1. 整车测试：各紧固件的锁紧扭力
零部件测试：
车闸：自行车类型，各紧固件的锁紧扭力
车把：自行车类型，车把横管和立管的锁紧扭力
车架：自行车类型，车架头管下端到轮轴距离，车轮尺寸
前叉：自行车类型，前叉使用在多大的车轮直径上（24”, 26”, 650B, 29”or700c，针对条款
车轮转动精度：自行车类型，车闸类型（Intended for rim-brakes， Not intended for rim-brakes）
脚踏：自行车类型
鞍座鞍管：自行车类型，鞍座锁紧扭力 产品标签，说明书
2. 关于反射器的测试ISO 6742‑2，客服同事须在进单前确认以下操作，三种情况其中一种，并在申请表中注明
a.申请测试；
b.提供报告：报告须有结论，报告型号与实际反射器型号一致，有效期1年；
c.此项目NT
Others 其他信息:
Photo for reference 参考图片:
Sample Report 参考报告
