ASME A 112.18.2返回 Back
| Test item 测试名称： Plumbing Waste Fittings 卫浴排水装置 | |
| Norm refer 涉及标准: CSA B 125.2 | |
| Test info 测试内容： | |
| Clause | Test Requirement |
| 4.1 | Materials 材料 |
| 4.1.3 | PP for tubular waste fittings (ASTM D4101) |
| 4.1.3 | ABS for tubular waste fittings(ASTM D3965) |
| 4.1.3 | PVC for tubular waste fittings(ASTM D1784 class 12454/14333) |
| 4.1.4 | ABS, PVC DWV for pipe and pipe fittings |
| 4.1.5 | Copper alloys 铜合金 (M>56%) |
| 4.1.6 | Cast iron |
| 4.1.7 | Ductile iron |
| 4.1.8 | Stainless steel alloys 不锈钢合金(300/400series) |
| Performance Test Fee | |
| 4.2 | Installation 安装 |
| 4.3 | Threads 螺纹 |
| 4.4 | Solder connections 焊接件 |
| 4.5 | Replacement parts 交换部件 |
| 4.6 | Dimensions 尺寸（Additional Requirment in Plumbing code: trap thickness>=1.1mm） |
| 4.6.1 | Outlet size 排污口尺寸 |
| 4.6.2 | Slip joints 滑配接头 |
| 4.6.3 | Wall thickness 壁厚 |
| 4.6.4 | Sink strainer assemblies 水槽过滤器安装 |
| 4.6.5 | Traps 存水湾 |
| 4.6.6 | Mechanical stoppers 机械塞子 |
| 4.6.7 | Elastomeric fittings 弹性的装置 |
| 4.6.8 | Tubing stops 管路截止 |
| 4.6.9 | Subdrains for built-up shower pans 用于组合式淋浴底盘的地下排水系统 |
| 5 | Performance requirements and test methods 性能要求与测试方法 |
| 5.2 | Corrosion 腐蚀 |
| 5.3 | Thermal cycling test 热循环测试 |
| 5.4 | Coating 涂层 |
| 5.5 | Shower drain strainers 淋浴排水过滤器 |
| 5.6 | Sink strainer assemblies 水槽过滤器安装 |
| 5.6.2 | Hot oil exposure 热油暴露测试 |
| 5.6.3 | Water absorption 吸水率 |
| 5.6.4 | Point impact 点冲击 |
| 5.7 | Body and clamping rings of subdrains for built-up shower pans 用于组合式淋浴底盘的地下排水系统的本体及锁紧环 |
| 5.8 | Minimum flow rates 最小流速 |
| 5.9 | Strength test 强度测定 |
| 5.9.1 | Thread torque strength test 螺纹扭力强度测试 |
| 5.9.2 | Hydraulic pressure 水压 |
| 5.1 | Life cycle test 使用寿命测试 |
| 5.11 | Seal leakage 密封泄漏 |
| 5 | Marking requirements 商标要求 |
| Sample required: 4 sets of completed products with assembly instruction (if applicable) ; 5 Kg raw material (for plastic fitting) | |
| 样品要求: 全套样品4套并包括安装说明书(如适用); 5 Kg 原材料粒子 （塑料下水） | |
| Turnaround time: Normal (9 working days - metal; 12 working days - plastic), Express (7working days). | |
| 所需时间: 标准(9个工作天 - 金属 ,12个工作天-塑料), 加快(7 个工作天). | |
Sample for reference 参考图片:
Sample Report 报告样本：
