DIN EN 14308返回 Back

Test or certification item 测试或认证名称: 建筑设备和工业装置的隔热保温产品.硬质聚氨酯泡沫及聚异氰脲酸酯产品.
Thermal insulation products for building equipment and industrial installations - Factory made rigid polyurethane foam (PUR) and polyisocyanurate foam (PIR) products


Test or certification info 测试和认证相关内容:

PU-Boards

Specimen preparation, storage and disposal

Specimen dimensions, density according to EN 822/823/1602 (flat products)

Closed cell content according to ISO 4590 with surface correction

Cell gas determination by gas chromatography (XPS)

Thermal conductivity - PU - normality test according to EN 14308

Thermal conductivity according to EN 12667 at -170 °C and in the temperature range from -75 °C to +25 °C, 5 measuring points

Thermal conductivity according to EN 12667 in the temperature range from 50 °C to 120 °C warm side temperature, 2 measuring points

Verification of the maximum service temperature according to EN 14706

Tensile strength according to EN 1607 at low temperatures (about -165 ° C)

Coefficient of thermal expansion and contraction - thermal change in length 23 °C to -165 °C


PU Pipe Section

Specimen dimensions, density according to EN 13467/13470 (preformed products)

Thermal conductivity according to EN ISO 8497 in the temperature range from -40 °C to 70 °C mean temperature (ΔT_mean = 50 K), 3 measuring points

Verification of the maximum service temperature according to EN 14707 PTD/CE (3times)



Responsive image

Responsive image


Responsive image


Responsive image

Responsive image


Norm refer 涉及法规:
CE, CPR

Refer products 涉及产品:  建材, 保温板

Lead time 周期:  常规服务 to be confirm 待定

Sample size 送样规格:  on request 待定

Others 其他信息:

Photo for reference 涉及图片:

Responsive image

Sample report 样本报告:
